Micron Mesh Cloth Sieves with Fine Filtration

Bolhes micron mesh sieves are mostly made using micron hole Dutch metal wire cloth as filtering media. The materials can be Stainless steel wire, copper wire, polyamide fiber or F46 wire.

This is a type of Woven wire mesh test sieves with flexible screening fabric and fine filtration rating.

Diameter:200mm,300mm,315mm,450mm

Aperture:25um-6.7mm

Sieve Material Composition:

Stainless steel mesh +stainless steel frame/Aluminium Fram

Stainless steel mesh+brass frame

Brass mesh+brass frame

Application:

The micron hole sieve is applied to exact mesh analysis, test, measure, classification for powdery material in lab, hospital, pharmacy, foodstuff, metallurgy, construction etc departments.

Features:

The frame of micron wire cloth testing sieve is made of SUS 304# stainless steel, the thickness is 0.6 mm, firm and durable, no magnetism.
Sieve and frame are soldered all around, then make a mosaic base, as the frame is two-double, so that the testing sieve is more firm and durable.
The micron wire testing sieve is processed by use special electrochemistry methods, and coated with chrome, so the surface of testing sieve is exact, glazed and wearable,it will not get distorted after long time use .

Diameter 300/200/100/75mm Micron Wire Cloth Processed Test Sieves:

Product name Micron Opening Standard Sieve
 Material  Stainless steel 304, Nickel Plated
 Technoloygy  Woven wire mesh/Perforated plate/ Electrical forming Nickel Plated
 Aperture   20 Micron-3mm / 3-150mm / 5-500 micron
 Hole shape  Square
 Standards  ISO3310, GB6003, ASTM, TYLER, JIS, DIN, BSI
 Framewall thickness  0.6mm - 0.7mm
 Functions  Particle size analysis
 Diameter  300mm / 200mm / 100mm / 75mm
Height (From top to sieve surface)  60mm / 50mm / 35mm / 30mm
 Weight  About 0.2-0.5Kg one piece
 Packaging  Carton/ Wooden case

Fine Woven Stainless Steel Wire Mesh Cloth Made Sieves

Fine Woven Stainless Steel Wire Mesh Cloth Made Sieves

Packed Wire Cloth Sieve Filters for Shipment

Packed Wire Cloth Sieve Filters for Shipment
